Intel Pentium Gold G5420 Processor (4M Cache, 3.80 GHz)

5,999.009,000.00 (-33%)

Only 1 left in stock

Intel Pentium Gold G5420

  • Intel Pentium Gold G5420 Processor (4M Cache, 3.80 GHz)
  • Intel Pentium Gold Processor SeriesProducts formerly Coffee LakeDesktopG542014 nm3.80 GHz4 MB Intel Smart Cache8 GT/s54 WIntel UHD Graphics 610350 MHz and 4k Graphics, at 60Hz
  • BX80684G5420
  • PG5420

Intel Pentium Gold G5420

  Intel Pentium Gold G5420 Specifications:

Vertical Segment Desktop
Processor Number G5420
Lithography 14 nm
Cores 2
Threads 4
Processor Base Frequency 3.80 GHz
Cache 4 MB Intel® Smart Cache
TDP 54 W
Supplemental Information
Embedded Options Available No
Memory Specifications
Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4-2400
Max # of Memory Channels 2
Max Memory Bandwidth 37.5 GB/s
ECC Memory Supported Yes
Graphics Specifications
Processor Graphics Intel® UHD Graphics 610
Graphics Base Frequency 350 MHz
Graphics Max Dynamic Frequency 1.05 GHz
Graphics Video Max Memory 64 GB
4K Support Yes, at 60Hz
Max Resolution (HDMI 1.4) 4096×2304@24Hz
DirectX Support 12
OpenGL Support 4.5
Intel® Quick Sync Video Yes
Intel® InTru™ 3D Technology Yes
Intel® Clear Video HD Technology Yes
Intel® Clear Video Technology Yes
Displays Supported 3
Expansion Options
Scalability 1S Only
PCI Express Revision 3.0
PCI Express Configurations Up to 1×16, 2×8, 1×8+2×4
Max # of PCI Express Lanes 16
Package Specifications
Sockets Supported FCLGA1151
Max CPU Configuration 1
Thermal Solution Specification PCG 2015C (65W)
Advanced Technologies
Intel® Optane™ Memory Supported Yes
Intel® Turbo Boost Technology No
Intel® vPro™ Platform Eligibility No
Intel® Hyper-Threading Technology Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel® VT-x with Extended Page Tables (EPT) Yes
Intel® Transactional Synchronization Extensions No
Intel® 64 Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Intel® Identity Protection Technology Yes
Intel® Stable Image Platform Program (SIPP) No
Security & Reliability
Intel® AES New Instructions Yes
Secure Key Yes
Intel® Software Guard Extensions (Intel® SGX) Yes with Intel® ME
Intel® Memory Protection Extensions (Intel® MPX) Yes
Intel® OS Guard Yes
Intel® Trusted Execution Technology No
Execute Disable Bit Yes
Intel® Boot Guard Yes
Warranty 3 Years
Note ***Features, Price and Specifications are subject to change without notice.


Read More:

Related Products:

Additional information

Weight .450 kg
Dimensions 11.6 × 7 × 10.1 cm
